[] High holding force! Up to 500 kg
[] Guaranteed performance: holding force tested on every Maglock
[] 500h salt spray resistant! SGS certified.
[] Tested according to ISO 9227
[] Special two-layer protective coating developed for outdoor use
[] Powdercoated aluminium casing
[] Anti-residual magnetism kick-off system
[] New anti-pry system: Raised edge on the magnet housing makes it impossible to put a crowbar between the magnet and the armature plate
[] Integrated handles
[] Fast and easy fixing by means of 7 holes with Quick-Fix
[] Same center-distance as the standard Locinox keeps
[] Fail open
[] MAG2500: Minimal pulling force: 2500N (250 kg)
[] MAG5000: Minimal pulling force: 5000N (500 kg)
[] Voltage: 12V/24V DC
[] Current MAG2500: 460 mA / 12 V or 230 mA / 24 V
[] Current MAG5000: 460 mA /12 V or 230 mA / 24 V
[] Guaranteed performance: holding force tested on every Maglock
[] 500h salt spray resistant! SGS certified.
[] Tested according to ISO 9227
[] Special two-layer protective coating developed for outdoor use
[] Powdercoated aluminium casing
[] Anti-residual magnetism kick-off system
[] New anti-pry system: Raised edge on the magnet housing makes it impossible to put a crowbar between the magnet and the armature plate
[] Integrated handles
[] Fast and easy fixing by means of 7 holes with Quick-Fix
[] Same center-distance as the standard Locinox keeps
[] Fail open
[] MAG2500: Minimal pulling force: 2500N (250 kg)
[] MAG5000: Minimal pulling force: 5000N (500 kg)
[] Voltage: 12V/24V DC
[] Current MAG2500: 460 mA / 12 V or 230 mA / 24 V
[] Current MAG5000: 460 mA /12 V or 230 mA / 24 V
Electro Magnetic Lock 500Kg with Handles
Code - FK574
$396.00 plus $25 shipping
Related Products
Electro-magnetic lock with handles
Locinox Magnetic locks for gates
Locinox Mag and MagMag locks
Electrical Requirement
The power for a electromagnetic lock is DC (Direct Current), It is around 5-6 W.The current is around 0.5 A when the voltage supply is 12VDC and 0.25A when using 24VDC (It may vary between manufacturers and if there are 1 or 2 coils in the block). Generally, the specification of the electromagnet lock is dual voltage of 12/24 VDC. If using a rectifier to convert AC power, a full wave bridge rectifier should be used.
The power for a electromagnetic lock is DC (Direct Current), It is around 5-6 W.The current is around 0.5 A when the voltage supply is 12VDC and 0.25A when using 24VDC (It may vary between manufacturers and if there are 1 or 2 coils in the block). Generally, the specification of the electromagnet lock is dual voltage of 12/24 VDC. If using a rectifier to convert AC power, a full wave bridge rectifier should be used.
